   Home      Omega Instruments      Pressure Switches






General Purpose Industrial Pressure Switches

Designed to satisfy most industrial switch requirements.




DPG1000 Series

Digital Pressure Gauges with Alarms and Analog Output Functions

  • AD or DC Powered with Dual Alarms
  • DC Powered with Dual Alarms and Analog Output
  • Ranges between 15 psi and 3000 psi
  • Normal or Reverse Acting Alarms
  • Hi/Lo, Hi/Hi, or Lo/Lo Alarms available


PSW-100

General Purpose Pressure Switches, In NEMA-4X Enclosures

  • UL Listed,
  • Ranges from 0.5 inH2O to 3000 psi
  • SPDT or DPDT Switches
  • Adjustment Lock
  • Safe, Easy Wiring Access



PSW-150

General Purpose Differential Pressure Switches

  • UL Listed
  • 15 Amp SPDT
  • Easy Adjustments
  • Vibration-Resistant Setpoints

PSW-850 Series

General Purpose Controls with Choice of Dual or Triple Switches

  • Two or Three-Switch Outputs — can Be Separated up to 100% of Range
  • Adjustable Pressure Ranges: inWC (inH2O) Ranges: -300 to 250 inH2O
    Pressure Ranges: 30 inHg Vac to 3000 psi (-1 to 206 bar)

PSW14 Series

Electronic Pressure Switch


  • Single Switch with Adjustable Hysteresis
  • Dual Switch with Fixed Hysteresis
  • Easy to Program On/Off Set Points
  • Compact Construction
  • Housing Rotates 320° Degrees




Low Pressure Switches

Designed to satisfy most industrial switch requirements.



PSW-141

Low Differential Pressure Switches, SPDT Relay Output

  • Virtually Impervious to changes in Position
  • Fast Response Time Due to Low Internal Volume
  • No Moving Parts - Solid State Circuity for Long Life
  • Compact Size
  • Low Power Consumption





Industrial Pressure Switches

Energize or de-energize electrical circuits as a function of whether the process pressure is normal or abnormal.



PXM509-IS Series

INTRINSICALLY SAFE PRESSURE TRANSMITTERS - Metric Models

  • High 0.08% Accuracy with NIST Traceable Calibration Certificate
  • 4 to 20 mA Output with FM Intrinsically Safe Rating
  • 316L SS Wetted Parts and Welded Stainless Steel Construction


PSW-180

Economical Differential Pressure Switches/Alarms


  • 5 Amp Relay or Built In Audible Alarm Available
  • Up to 150 PSI Operating Pressure
  • NEMA-4 Rated Housing

PSW-190

Economical Brass Pressure Switches


  • Available Buna-N or FKM Diaphragm and O-ring
  • Contacts Rated for 5 Amps at 250 Vac or 30 Vdc
  • Pigtail Lead with Conduit Connection
  • High Operating Pressure

PSW-581

Economical OEM Pressure Switches, Vacuum to 500 psi

  • Sensor: Aluminum diaphragm
  • Enclosure: Switch actuator and bracket steel: irridite finish; adjusting cap and body: zinc alloy chromate finish
  • Pressure Port: ¼ NPT male


PSW-620/PSW-630 Series

Economical Pressure and Vacuum Switches


  • External Pressure Scale and Pointer for Easy Setpoint Adjustment
  • Silver Switch Contacts Rated for 5 Amps @ 250 Vac or 3 Amps @ 28 Vdc
  • 1 Amp Gold-Plated Contacts for TTL or Dry Contacts




PSW-680 Series

Low Pressure/Vacuum Switches


  • Compound Range Covers Vacuum and Pressure in One Unit
  • Low Inch of Water Ranges
  • Silver Switch Contacts Rated for 5 Amps @ 250 Vac
  • 1 Amp, Gold-Plated Contacts for TTL or Dry Contacts

PSW-690 Series

High Purity Pressure/Vacuum Switches with All Stainless Steel Wetted Parts
  •  All Stainless Steel Wetted Parts
  • Sensing Element Capsule, Electron Beam Welded
  • Helium Leak Tested 4 x 10-9 STD CC/sec
  • Available with 1/4 VCR Male or 1/8-27 NPT Male Fittings

PSW-800

Economical Industrial Pressure Switches for Vacuum to 7500 psi

  • UL and CSA Marked
  • Easy Adjustment with Locking Set Screw
  • Rugged Industrial Design
  • Standard 1 /2 " Female Conduit Fitting for Electrical Termination


PSW14 Series

Electronic Pressure Switch


  • Single Switch with Adjustable Hysteresis
  • Dual Switch with Fixed Hysteresis
  • Easy to Program On/Off Set Points
  • Compact Construction
  • Housing Rotates 320° Degrees


PSW845 Series

Differential Pressure Switch

  • Rugged Differential Switch with Excellent Bypass Characteristics
  • 0.25A SPDT Switch
  • Ranges to 250 PSID
  • Steel, Anodized Aluminum, Buna and Loctite #271 Wetted Parts






Miniature Pressure Switches

Capable of sensing very low positive or negative pressures, reliability and long life are inherent advantages of this design.




PSW-500

Miniature Pressure and Vacuum Switches


  • External Pressure Scale and Pointer for Easy Setpoint Adjustments
  • 5 Amp Model Switches With High Proof Pressures
  • 1 Amp Gold-Plated Switches for TTL and Dry Contact Closures
  • Wetted Parts: Stainless Steel, Sealing Compound and or O-ring

PSW-690 Series

High Purity Pressure/Vacuum Switches with All Stainless Steel Wetted Parts
  •  All Stainless Steel Wetted Parts
  • Helium Leak Tested 4 x 10-9 STD CC/sec
  • External Pressure Scale and Pointer For Easy Set Point Adjustment
  • Available with 1/4 VCR Male or 1/8-27 NPT Male Fittings

PSW845 Series

Differential Pressure Switch


  • Rugged Differential Switch with Excellent Bypass Characteristics
  • 0.25A SPDT Switch
  • Ranges to 250 PSID
  • Fitting: 1/4-18 NPT female
    Electrical Connection: 300 mm (12") pigtail leads, 24 AWG

HW3000 Series

PVC Hook Up Wire, 300 V UL appliance wire


  • PVC Insulated Appliance Hook Up Wire
  • Operating Temperature:
    - 40 to 105°C (-40 to 221°F)
    - UL AWM 1569
    - 40 to 90°C (-40 to 194°F)
    - CSA TR-64
    - 40 to 80°C (-40 to 176°F)
    - UL AWM 1007






Solid State and Digital Pressure Switches

Read data quick with digital meters.



DPG1000

Digital Pressure Gauges and Models with Alarm and Analog Outputs

  • Dual Alarm and Signal Alarm plus Analog Output
  • ±0.25% Test Gauge Accuracy
  • 316 Stainless Steel Wetted Parts
  • 1/4 -18 NPT
  • Loop Test Function
  • Easy-to-Read 3½ Digit LCD Display



DPG1001 Series

High Accuracy Digital Pressure Gauges with NIST Certification

  • NIST Certification Included
  • High Accuracy +/- 0.10% Test Gauge
  • 316 Stainless Steel Wetted Parts
  •  1/4 -18 NPT
  • Easy-to-Read 3 1/2 Digit LCD Display
  • Rugged Aluminum Case

DPG9000 Series

Industrial Digital Pressure Gauges, DC, Loop, or Battery Powered Models

  • A Multi-Functional Digital Gauge with Optional 4 to 20 mA Output and (1) or (2) SPDT Switches
  • ±0.25% of Span Terminal Point Accuracy
  • IP65 (NEMA 4) Weatherproof Case
  • 3" Stainless Steel Case or 4 1/2" Fiberglass Reinforced Thermoplastic Case

PSW14 Series

Electronic Pressure Switch


  • Single Switch with Adjustable Hysteresis
  • Dual Switch with Fixed Hysteresis
  • Easy to Program On/Off Set Points
  • Compact Construction
  • Housing Rotates 320° Degrees
  • Process Connection: ¼ NPT Male


PSW2000 Series

Digital Pressure Switch with Display and Solid State Sensor

  • 3-Digit Red LED Display
  • Two Outputs
    Either 2 Solid State Switches or 1 Switch and 1 Analog Output
  • 10 Bit A/D Converter
  • Process Connection: ¼-18 NPT
  • High Accuracy with Fully Adjustable Deadband

PSW3000 Series

Multi Output Electronic Pressure Switch

  • 4 Switching Outputs with Optional Analog Pressure Output
  • Process Connection: ¼ FNPT
  • High Accuracy with Adjustable Deadband Individually Settable
  • Easy to Read LCD with Scalable Bar Graph
